gefran VDI100 Start-Up And Installation Manual

Group 04: External Analog Input and Output Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
04-19 AO2 Output Signal Type
0: AO2 0~10V
0 - O O O O O O O
1: AO2 4~20mA
04-20
Filter Time of AO Signal
Scan
0.00~0.50 0.00 s O O O O O O O *1
Group 05: Multi-Speed Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
05-00
Acceleration and Decelera-
tion Selection of Multi-Spe-
ed
0: Acceleration and deceleration time are
set by 00-14 ~ 00-24
0 - O O O O O O O
1: Acceleration and Deceleration Time are
set by 05-17 ~ 05-48
05-01
*Frequency Setting of
Speed-Stage 0
0.00~599.00 5.00 Hz O O O O O O O *1
05-02
*Frequency Setting of
Speed-Stage 1
0.00~599.00 5.00 Hz O O O O O O O *1
05-03
*Frequency Setting of
Speed-Stage 2
0.00~599.00 10.00 Hz O O O O O O O *1
05-04
*Frequency Setting of
Speed-Stage 3
0.00~599.00 20.00 Hz O O O O O O O *1
05-05
*Frequency Setting of
Speed-Stage 4
0.00~599.00 30.00 Hz O O O O O O O *1
05-06
*Frequency Setting of
Speed-Stage 5
0.00~599.00 40.00 Hz O O O O O O O *1
05-07
*Frequency Setting of
Speed-Stage 6
0.00~599.00 50.00 Hz O O O O O O O *1
05-08
*Frequency Setting of
Speed-Stage 7
0.00~599.00 50.00 Hz O O O O O O O *1
05-09
*Frequency Setting of
Speed-Stage 8
0.00~599.00 5.00 Hz O O O O O O O *1
05-10
*Frequency Setting of
Speed-Stage 9
0.00~599.00 5.00 Hz O O O O O O O *1
05-11
*Frequency Setting of
Speed-Stage 10
0.00~599.00 5.00 Hz O O O O O O O *1
05-12
*Frequency Setting of
Speed-Stage 11
0.00~599.00 5.00 Hz O O O O O O O *1
05-13
*Frequency Setting of
Speed-Stage 12
0.00~599.00 5.00 Hz O O O O O O O *1
05-14
*Frequency Setting of
Speed-Stage 13
0.00~599.00 5.00 Hz O O O O O O O *1
05-15
*Frequency Setting of
Speed-Stage 14
0.00~599.00 5.00 Hz O O O O O O O *1
05-16
*Frequency Setting of
Speed-Stage 15
0.00~599.00 5.00 Hz O O O O O O O *1
05-17
Acceleration Time Setting
of Multi Speed 0
0.1~6000.0 10.0 s O O O O O O O
05-18
Deceleration Time Setting
of Multi Speed 0
0.1~6000.0 10.0 s O O O O O O O
05-19
Acceleration Time Setting
of Multi Speed 1
0.1~6000.0 10.0 s O O O O O O O
05-20
Deceleration Time Setting
of Multi Speed 1
0.1~6000.0 10.0 s O O O O O O O
05-21
Acceleration Time Setting
of Multi Speed 2
0.1~6000.0 10.0 s O O O O O O O
05-22
Deceleration Time Setting
of Multi Speed 2
0.1~6000.0 10.0 s O O O O O O O
05-23
Acceleration Time Setting
of Multi Speed 3
0.1~6000.0 10.0 s O O O O O O O
VDI100 • Start-up and Installation Manual 37
