gefran VDI100

Group 05: Multi-Speed Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
05-24
Deceleration Time Setting
of Multi Speed 3
0.1~6000.0 10.0 s O O O O O O O
05-25
Acceleration Time Setting
of Multi Speed 4
0.1~6000.0 10.0 s O O O O O O O
05-26
Deceleration Time Setting
of Multi Speed 4
0.1~6000.0 10.0 s O O O O O O O
05-27
Acceleration Time Setting
of Multi Speed 5
0.1~6000.0 10.0 s O O O O O O O
05-28
Deceleration Time Setting
of Multi Speed 5
0.1~6000.0 10.0 s O O O O O O O
05-29
Acceleration Time Setting
of Multi Speed 6
0.1~6000.0 10.0 s O O O O O O O
05-30
Deceleration Time Setting
of Multi Speed 6
0.1~6000.0 10.0 s O O O O O O O
05-31
Acceleration Time Setting
of Multi Speed 7
0.1~6000.0 10.0 s O O O O O O O
05-32
Deceleration Time Setting
of Multi Speed 7
0.1~6000.0 10.0 s O O O O O O O
05-33
Acceleration Time Setting
of Multi Speed 8
0.1~6000.0 10.0 s O O O O O O O
05-34
Deceleration Time Setting
of Multi Speed 8
0.1~6000.0 10.0 s O O O O O O O
05-35
Acceleration Time Setting
of Multi Speed 9
0.1~6000.0 10.0 s O O O O O O O
05-36
Deceleration Time Setting
of Multi Speed 9
0.1~6000.0 10.0 s O O O O O O O
05-37
Acceleration Time Setting
of Multi Speed 10
0.1~6000.0 10.0 s O O O O O O O
05-38
Deceleration Time Setting
of Multi Speed 10
0.1~6000.0 10.0 s O O O O O O O
05-39
Acceleration Time Setting
of Multi Speed 11
0.1~6000.0 10.0 s O O O O O O O
05-40
Deceleration Time Setting
of Multi Speed 11
0.1~6000.0 10.0 s O O O O O O O
05-41
Acceleration Time Setting
of Multi Speed 12
0.1~6000.0 10.0 s O O O O O O O
05-42
Deceleration Time Setting
of Multi Speed 12
0.1~6000.0 10.0 s O O O O O O O
05-43
Acceleration Time Setting
of Multi Speed 13
0.1~6000.0 10.0 s O O O O O O O
05-44
Deceleration Time Setting
of Multi Speed 13
0.1~6000.0 10.0 s O O O O O O O
05-45
Acceleration Time Setting
of Multi Speed 14
0.1~6000.0 10.0 s O O O O O O O
05-46
Deceleration Time Setting
of Multi Speed 14
0.1~6000.0 10.0 s O O O O O O O
05-47
Acceleration Time Setting
of Multi Speed 15
0.1~6000.0 10.0 s O O O O O O O
05-48
Deceleration Time Setting
of Multi Speed 15
0.1~6000.0 10.0 s O O O O O O O
* If the maximum output frequency of motor is over 300HZ, the frequency resolution is changed to 0.1Hz
Group 06: Automatic Program Operation Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
06-00
Auto Run (sequencer) mode
selection
0: Disabled 0 - O O O X X X O
38 VDI100 • Start-up and Installation Manual
