gefran VDI100

Group 06: Automatic Program Operation Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
06-22
Operation Time Setting of
Speed-Stage 6
0.0~6000.0 0.0 s O O O X X X O *1
06-23
Operation Time Setting of
Speed-Stage 7
0.0~6000.0 0.0 s O O O X X X O *1
06-24
Operation Time Setting of
Speed-Stage 8
0.0~6000.0 0.0 s O O O X X X O *1
06-25
Operation Time Setting of
Speed-Stage 9
0.0~6000.0 0.0 s O O O X X X O *1
06-26
Operation Time Setting of
Speed-Stage 10
0.0~6000.0 0.0 s O O O X X X O *1
06-27
Operation Time Setting of
Speed-Stage 11
0.0~6000.0 0.0 s O O O X X X O *1
06-28
Operation Time Setting of
Speed-Stage 12
0.0~6000.0 0.0 s O O O X X X O *1
06-29
Operation Time Setting of
Speed-Stage 13
0.0~6000.0 0.0 s O O O X X X O *1
06-30
Operation Time Setting of
Speed-Stage 14
0.0~6000.0 0.0 s O O O X X X O *1
06-31
Operation Time Setting of
Speed-Stage 15
0.0~6000.0 0.0 s O O O X X X O *1
06-32
Operation Direction Se-
lection of Speed-Stage 0
0: Stop
0 - O O O X X X O1: Forward
2: Reverse
06-33
Operation Direction Se-
lection of Speed-Stage 1
0: Stop
0 - O O O X X X O1: Forward
2: Reverse
06-34
Operation Direction Se-
lection of Speed-Stage 2
0: Stop
0 - O O O X X X O1: Forward
2: Reverse
06-35
Operation Direction Se-
lection of Speed-Stage 3
0: Stop
0 - O O O X X X O1: Forward
2: Reverse
06-36
Operation Direction Se-
lection of Speed-Stage 4
0: Stop
0 - O O O X X X O1: Forward
2: Reverse
06-37
Operation Direction Se-
lection of Speed-Stage 5
0: Stop
0 - O O O X X X O1: Forward
2: Reverse
06-38
Operation Direction Se-
lection of Speed-Stage 6
0: Stop
0 - O O O X X X O1: Forward
2: Reverse
06-39
Operation Direction Se-
lection of Speed-Stage 7
0: Stop
0 - O O O X X X O1: Forward
2: Reverse
06-40
Operation Direction Se-
lection of Speed-Stage 8
0: Stop
0 - O O O X X X O1: Forward
2: Reverse
06-41
Operation Direction Se-
lection of Speed-Stage 9
0: Stop
0 - O O O X X X O1: Forward
2: Reverse
06-42
Operation Direction Se-
lection of Speed-Stage 10
0: Stop
0 - O O O X X X O1: Forward
2: Reverse
06-43
Operation Direction Se-
lection of Speed-Stage 11
0: Stop
0 - O O O X X X O1: Forward
2: Reverse
40 VDI100 • Start-up and Installation Manual
