gefran VDI100 Start-Up And Installation Manual

Group 06: Automatic Program Operation Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
06-44
Operation Direction Se-
lection of Speed-Stage 12
0: Stop
0 - O O O X X X O1: Forward
2: Reverse
06-45
Operation Direction Se-
lection of Speed-Stage 13
0: Stop
0 - O O O X X X O1: Forward
2: Reverse
06-46
Operation Direction Se-
lection of Speed-Stage 14
0: Stop
0 - O O O X X X O1: Forward
2: Reverse
06-47
Operation Direction Se-
lection of Speed-Stage 15
0: Stop
0 - O O O X X X O1: Forward
2: Reverse
* If the maximum output frequency of motor is over 300HZ,the frequency resolution is changed to 0.1Hz
Group 07: Start /Stop Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
07-00
Momentary Power Loss/
Fault Restart Selection
0: Disable
0 - O O O O X O O
1: Enable
07-01 Fault Auto-Restart Time 0~7200 0 s O O O O O O O
07-02
Number of Fault Auto-Re-
start Attempts
0~10 0 - O O O O O O O
07-03 Reserved
07-04 Direct Start at Power on
0: When the external run command is
enabled, direct start at power up
1 - O O O O O O O
1: When the external run command is
enabled, unable to direct start at power-
up.
07-05
Delay of Direct Start at
Power on
1.0~300.0 3.5 s O O O O O O O
07-06
DC Injection Braking Star-
ting Frequency
0.0~10.0 0.5 Hz O O O O O O O
07-07 DC Injection Braking Current 0~100 50 % O O O X X O O
07-08
DC Injection Braking Time
at Stop
0.00~100.00 0.50 s O O O O O O O
07-09 Stop Mode Selection 0: Deceleration to Stop
0 - O O O O
O O
O
1: Coast to Stop O O
2: DC Braking Stop in All Fields X X
3: Coast to Stop with Timer O O
07-10
~
07-12
Reserved
07-13
Low Voltage Detection
Level
250~600 380 V O O O O O O O
07-14 Pre-excitation Time 0.00~10.00 2.00 s X X O X X X X
07-15 Pre-excitation Level 50~200 100 % X X O X X X X
07-16
DC Injection Braking Time
at Start
0.00~100.00 0.00 s O O O O O O O
07-17 Reserved
07-18 Minimum Base block Time 0.1~5.0 - s O O O O X O O
07-19
Direction-Detection Speed
Search Operating Current
0~100 50 % O X O X X X O
07-20
Speed Search Operating
Current
0~100 20 % O X O X X X O
07-21
Integral Time of Speed
Searching
0.1~10.0 2.0 s O X O X X X O
07-22
Delay Time of Speed
Searching
0.0~20.0 0.2 s O O O O O X O
VDI100 • Start-up and Installation Manual 41
