Group 07: Start /Stop Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
07-23 Voltage Recovery Time 0.1~5.0 2.0 s O O O X X X O
07-24
Direction-Detection Speed
Search Selection
0: Disable
1 - O O O X X X O
1: Enable
07-25 Low Voltage Detection Time 0.00~1.00 0.02 s O O O O O O O
07-26
Start-up Mode Selection of
SLV Coast to Stop
0: Start with speed search
0 - X X O X X X X
1: Normal start
07-27
Start Selection after Fault
during SLV Mode
0: Start with speed search
0 - X X O X X X X
1: Normal start
07-28
Start after External Base
Block
0: Start with speed search
0 - O X O X X X O
1: Normal start
07-29
Run Command Selection at
the Action of DC Braking
0: Not Allowable to Run
0 - O O X X X X X
1: Allowable to Run
07-30 Low Voltage Level Selection
0: Disable
0 - O O O O O O O
1: Enable
07-31
**Low Voltage Run Fre-
quency
0.00~599.00 10.00 Hz X X X O O X X
07-32
Speed Search Mode
Selection
0: Disable
0 - O O O O X O X
1: Execute a Speed Search at Power On
2: Execute a Speed Search each time
07-33
Start Frequency of Speed
Search Selection
0: Maximum Output Frequency of Motor
0 - O O O O X X X
1: Frequency Command
07-34
Short-circuit braking time
at start
0.00~100.00 0.00 s X X X X X O X
07-35
Short-circuit braking time
at stop
0.00~100.00 0.50 s X X X X X O X
07-36
Short-circuit braking current
limited
0.0~200.0 100.0 % X X X X X O X
07-37
~
07-41
Reserved
07-42 Voltage Limit Gain 0.0~50.0 0 % X X O O X X X Note 1
07-43
Short-circuit Braking Time
of PM Speed Search
0.00~100.00 0.0 s X X X X X O X Note 1
07-44
DC Braking Time of PM
Speed Search
0.00~100.00 0.0 s X X X X X O X Note 1
*07-13 Low Voltage Detection Level, it is enable when 07-30 Low Voltage Level Selection set 0 (Enable) and lower frequency limit set to 250V.This application is for Emergency
power supply (EPS)
* *If the maximum output frequency of motor is over 300HZ,the frequency resolution is changed to 0.1Hz
Group 08: Protection Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
08-00 Stall Prevention Function
xxx0b: Stall prevention is enabled in
acceleration.
0000b - O O O O O O O
xxx1b: Stall prevention is disabled in
acceleration.
xx0xb: Stall prevention is enabled in
deceleration.
xx1xb: Stall prevention is disabled in
deceleration.
x0xxb: Stall prevention is enabled in
operation
x1xxb: Stall prevention is disabled in
operation
0xxxb: Stall prevention in operation is
based on deceleration time of speed-sta-
ge 1.
1xxxb: Stall prevention in operation is
based on deceleration time of speed-sta-
ge 2.
42 VDI100 • Start-up and Installation Manual
