gefran VDI100 Start-Up And Installation Manual

Group 08: Protection Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
08-01
Stall Prevention Level in
Acceleration
20~200
HD:150
% O O O X X O O
ND:120
08-02
Stall Prevention Level in
Deceleration
660V~820V 770V V O O O O X O O
08-03
Stall Prevention Level in
Operation
30~200
HD:160
% O O X X X X O
ND:120
08-04 Reserved
08-05
Selection for Motor Overload
Protection (OL1)
xxx0b: Overload Protection is disabled. 0001b - O O O O O O O
xxx1b: Overload Protection is enabled.
xx0xb: Cold Start of Motor Overload
xx1xb: Hot Start of Motor Overload
x0xxb: Standard Motor
x1xxb: Inverter Duty Motor
0xxxb: Reserved
1xxxb: Reserved
08-06
Start-up Mode of Overload
Protection Operation (OL1)
0: Stop Output after Overload Protection
0 - O O O O O O O
1: Continuous Operation after Overload
Protection.
08-07
Motor Overload (OL1)
Protection Level
0: Motor Overload (OL1) Protection 0
0 - O O O O O O O Note 11: Motor Overload (OL1) Protection 1
2: Motor Overload (OL1) Protection 2
08-08
Automatic Voltage Regula-
tion (AVR)
0: Enable
0 - O O O O O O O
1: Disable
08-09
Selection of Input Phase
Loss Protection
0: Enable
0 - O O O O O O O
1: Disable
08-10
Selection of Output Phase
Loss Protection
0: Enable
0 - O O O O O O O
1: Disable
08-11
~
08-12
Reserved
08-13
Selection of Over-Torque
Detection
0: Over-Torque Detection is Disabled. 0 - O O O O O O O
1: Start to Detect when Reaching the Set
Frequency.
2: Start to Detect when the Operation is
Begun.
08-14
Selection of Over-Torque
Operation
0: Deceleration to Stop when Over Torque
is Detected.
0 - O O O O O O O
1: Display Warning when Over Torque is
Detected. Go on Operation.
2: Coast to Stop when Over Torque is
Detected
08-15
Level of Over-Torque
Detection
0~300 150 % O O O O O O O
08-16
Time of Over-Torque
Detection
0.0~10.0 0.1 s O O O O O O O
08-17
Selection of Low-Torque
Detection
0: Low-Torque Detection is Disabled. 0 - O O O O O O O
1: Start to Detect when Reaching the Set
Frequency.
2: Start to Detect when the Operation is
Begun.
08-18
Selection of Low-Torque
Operation
0: Deceleration to Stop when Low Torque
is Detected.
0 - O O O O O O O
1: Display Warning when Low Torque is
Detected. Go on Operation.
2: Coast to Stop when Low Torque is
Detected
VDI100 • Start-up and Installation Manual 43
