Group 08: Protection Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
08-19
Level of Low-Torque
Detection
0~300 30 % O O O O O O O
08-20
Time of Low-Torque De-
tection
0.0~10.0 0.1 s O O O O O O O
08-21
Limit of Stall Prevention in
Acc over Base Speed
1~100 50 % O O O X X O O
08-22
Stall Prevention Detection
Time in Operation
2~100 100 ms O O O X X O O
08-23 Ground Fault (GF) Selection
0: Disable
0 - O O O O O O O
1: Enable
08-24
External Fault Operation
Selection
0: Deceleration to Stop 0 - O O O O O O O
1: Coast to Stop
2: Continuous Operation
08-25
Detection Selection of
External Fault
0: Immediately Detect when the Power is
Supplied.
0 - O O O O O O O
1: Start to Detect when the Operation is
Started.
08-26
~
08-29
Reserved
08-30
Digital Input Stop Command
Selection
0: Deceleration to Stop
0 - O O O O O O O
1: Coast to Stop
08-31
~
08-34
Reserved
08-35
Motor Overheat Fault
Selection
0: Disable 0 - O O O O O O O
1: Deceleration to Stop
2: Free Run to top
3: Continue Running
08-36
PTC Input Filter Time
Constant
0.00 ~ 10.00 2 s O O O O O O O
08-37 Fan Control Function 0: Start in operation 0 O O O O O O O
1: Permanent Start
2: Start in high temperature (Note)
08-38 Delay Time of Fan Off 0~600 60 s O O O O O O O
08-39
Delay Time of Motor Overhe-
at Protection
1~300 60 sec O O O O O O O
08-40
Motor2 Acceleration Stall
Prevention Level
20~200
HD:150
% O O O X X O O
ND:120
08-41
Motor2 Acceleration Stall
Prevention Limit
1~100 50 % O O O X X O O
08-42 PTC Protection Level 0.1~10.0V 0.7 V O O O O O O O
08-43 PTC Restart Level 0.1~10.0V 0.3 V O O O O O O O
08-44 PTC Warning Level 0.1~10.0V 0.5 V O O O O O O O
Note 1: New added parameter in software V1.20.
Group 09: Communication Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
09-00
INV Communication Station
Address
1~31 1 - O O O O O O O *3
09-01
Communication Mode
Selection
0: MODBUS 0 O O O O O O O
*3
*5
1: Reserved
2: Reserved
44 VDI100 • Start-up and Installation Manual
