gefran VDI100 Start-Up And Installation Manual

Group 09: Communication Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
3: Reserved
4: PROFIBUS*
09-02 Baud Rate Setting (bps) 0: 1200 4 - O O O O O O O *3
1: 2400
2: 4800
3: 9600
4: 19200
5: 38400
09-03 Stop Bit Selection 0: 1 Stop Bit 0 - O O O O O O O *3
1: 2 Stop Bit
09-04 Parity Selection 0: No Parity 0 - O O O O O O O *3
1: Even Bit
2: Odd Bit
09-05
Communication Data Bit
Selection
0: 8 Bit Data 0 - O O O O O O O *3
1: 7 Bit Data
09-06
Communication Error
Detection Time
0.0~25.5 0.0 S O O O O O O O
09-07 Fault Stop Selection
0: Deceleration to Stop Based on Decele-
ration Time 1 when Communication Fault
Occurs.
3 - O O O O O O O *3
1: Coast to Stop when Communication
Fault Occurs.
2: Deceleration to Stop Based on Decele-
ration Time 2 when Communication Fault
Occurs.
3: Keep Operating when Communication
Fault Occurs.
09-08
Comm. Fault Tolerance
Count
1~20 1 - O O O O O O O *3
09-09 Waiting Time 5~65 5 ms O O O O O O O *3
09-10 Reserved
* Selection of item 4 in parameter 09-01 is required to be coupled with the Profibus card.
* Parameter 09 does not be influenced by 13-08 (Restore Factory Setting)
Group 10: PID Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
10-00
PID Target Value Source
Setting
1: AI1 given 1 - O O O O O O O
2: AI2 given
3: PI given
4:10-02 given
5: Reserved
6: Frequency Command (00-05)
10-01
PID Feedback Value Source
Setting
1: AI1 given 2 - O O O O O O O
2: AI2 given
3: PI given
10-02 PID Target Value 0.00~100.00 0.00 % O O O O O O O *1
10-03 PID Control Mode xxx0b: PID Disable 0000b - O O O O O O O
xxx1b: PID Enable
xx0xb: PID Positive Characteristic
xx1xb: PID Negative Characteristic
x0xxb: PID Error Value of D Control
x1xxb: PID Feedback Value of D Ctrl
VDI100 • Start-up and Installation Manual 45
