Group 10: PID Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
11: °F
12: inW
13: HP
14: m/s
15: MPM
16: CMM
17: W
18: kW
19: m
20: °C
21: rpm
22: Bar
23: Pa
24: kPa
10-36 Proportional Gain 2 (P) 0.00~10.00 3.00 O O O O O O O Note 1
10-37 Integral Time 2 (I) 0.00~100.00 0.50 s O O O O O O O Note 1
10-38 Differential Time 2 (D) 0.00~10.00 0.00 s O O O O O O O Note 1
10-39
*Output Frequency Setting
of PID Disconnection
00.00~599.00 30.00 Hz O O O O O O O
10-40
Selection of PID Sleep Com-
pensation Frequency
0: Disable
0 O O O O O O O
1: Enable
10-41 PID Mode Switch
0: General PID
0 - O O O O O O O Note 1
1: D Type PID
* If the maximum output frequency of motor is over 300Hz, the frequency resolution is changed to 0.1Hz
Note 1: New added parameter in software V1.20.
Group 11: Auxiliary Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
11-00 Direction Lock Selection 0: Allow Forward and Reverse Rotation 0 - O O O O O O O
1: Only Allow Forward Rotation
2: Only Allow Reverse Rotation
11-01 Carrier frequency 0: Carrier Output Frequency Tuning * - O O O O O O O
1~16: 1~16kHz *1
11-02
Soft PWM Function
Selection
0: Disable
0 - O O O O O O O
1: Soft PWM 1 enables
2: Soft PWM 2 enables
11-03
Automatic carrier lowering
selection
0: Disable 0 - O O X X X X O
1: Enable
11-04
S-curve Time Setting at the
Start of Acceleration
0.00~2.50 0.20 s O O O O O O O
11-05
S-curve Time Setting at the
Stop of Acceleration
0.00~2.50 0.20 s O O O O O O O
11-06
S-curve Time Setting at the
Start of Deceleration
0.00~2.50 0.20 s O O O O O O O
11-07
S-curve Time Setting at the
Stop of Deceleration
0.00~2.50 0.20 s O O O O O O O
11-08 Jump Frequency 1 0.0~599.0 0.0 Hz O O O O O O O
11-09 Jump Frequency 2 0.0~599.0 0.0 Hz O O O O O O O
11-10 Jump Frequency 3 0.0~599.0 0.0 Hz O O O O O O O
11-11 Jump Frequency Width 0.0~25.5 1.0 Hz O O O O O O O
11-12 Manual Energy Saving Gain 0~100 80 % O O X X X X X
11-13 Automatic Return Time 0~120 60 s O O O O O O O *1
11-14
~
11-17
Reserved
VDI100 • Start-up and Installation Manual 47
