gefran VDI100 Start-Up And Installation Manual

Group 11: Auxiliary Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
11-18
Manual Energy Saving
Frequency
0.0~599.0 0.00 Hz O O X X X X X
11-19
Automatic Energy Saving
Function
0: Automatic energy saving is disabled. 0 - O X X X X X X
1: Automatic energy saving is enabled.
11-20
Filter Time of Automatic
Energy Saving
0~200 140 ms O X X X X X X
11-21
Voltage Upper Limit of
Energy Saving Tuning
0~100 100 % O X X X X X X
11-22
Adjustment Time of Auto-
matic Energy Saving
0~5000 20 ms O X X X X X X *1
11-23
Detection Level of Automa-
tic Energy Saving
0~100 10 % O X X X X X X
11-24
Coefficient of Automatic
Energy Saving
0.00~655.35 S - O X X X X X X
11-25
~
11-27
Reserved
11-28
Frequency Gain of Over
Voltage Prevention 2
1~200 100 % O O X X X X X
11-29 Auto De-rating Selection 0: Disable 0 - O X X X X X O
1: Enable
11-30
Variable Carrier Frequency
Max. Limit
2~16 - kHz O O X X X X O
11-31
Variable Carrier Frequency
Min. Limit
1~16 - kHz O O X X X X O
11-32
Variable Carrier Frequency
Proportional Gain
00~99 00 - O O X X X X O
11-33
DC Voltage Filter Rise
Amount
0.1~10.0 0.1 Vdc O O X X X X X *1
11-34
DC Voltage Filter Fall
Amount
0.1~10.0 5.0 Vdc O O X X X X X *1
11-35
DC Voltage Filter Dead band
Level
0.0~99.0 10.0 Vdc O O X X X X X *1
11-36
Frequency Gain of OV
Prevention
0.000~1.000 0.050 - O O X X X X X *1
11-37
**Frequency Limit of OV
Prevention
0.00~599.00 5.00 Hz O O X X X X X
11-38
Deceleration Start Voltage
of OV Prevention
400~800V 700 V O O X X X X X
11-39
Deceleration Stop Voltage
of OV Prevention
600~800V 750 V O O X X X X X
11-40 OV Prevention Selection 0: Disable 0 - O O X X X X X
1: OV Prevention Mode 1
2: OV Prevention Mode 2
3: OV Prevention Mode 3
11-41 Selection of Reference
Frequency Disappearance
Detection
0: Decelerate to Stop when Reference
Frequency Disappears
0 - O O O O O O O
1: Operation is set by Parameter 11-42
when Reference Frequency Disappears
11-42
Disappearance Level of
Reference Frequency
0.0~100.0 80.0 % O O O O O O O
11-43 Hold Frequency at Start 0.0~599.0 0.0 Hz O O O O O O O
11-44
Frequency Hold Time at
Start
0.0~10.0 0.0 s O O O O O O O
11-45 Hold Frequency at Stop 0.0~599.0 0.0 Hz O O O O O O O
11-46
Frequency Hold Time at
Stop
0.0~10.0 0.0 s O O O O O O O
11-47 KEB Deceleration Time 0.0~25.5 0.0 s O O X X X X O *1
11-48 KEB Detection Level 380~420 400 V O O X X X X O
11-49 Zero-servo Gain 0.01~5.00
1.00 - X X X O O X X
11-50 Zero-servo Count 0~4096 12 - X X X O O X X
11-51
Braking Selection of Zero
Speed
0: Disable 0 - O X X X X X O
1: Enable
11-52 Droop Control Level 0.0~100.0% 0.0 % X X X O O X X *1
48 VDI100 • Start-up and Installation Manual
