Group 11: Auxiliary Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
11-53 Droop Control Delay 0.01~2.00 0.2 s X X X O O X X *1
11-54
Initialization of Cumulative
Energy
0: Do not Clear Cumulative Energy 0 - O O O O O O O *1
1: Clear Cumulative Energy
11-55 STOP Key Selection
0: Stop Key is Disabled when the
Operation Command is not Provided by
Operator.
1 - O O O O O O O
1: Stop Key is Enabled when the
Operation Command is not Provided by
Operator.
11-56 UP/DOWN Selection
0: When UP/DOWN in Keypad is Disabled,
it will be Enabled if Pressing ENTER after
Frequency Modification.
0 - O O O O O O O
1: When UP/DOWN in Keypad is Enabled,
it will be Enabled upon Frequency Modi-
fication.
11-57 Reserved
11-58
Record Reference Fre-
quency
0: Disable 0 - O O O O O O O *1
1: Enable
11-59
Gain of Preventing Oscil-
lation
0.00~2.50 * O O X X X X O
11-60
Upper Limit of Preventing
Oscillation
0~100 * % O O X X X X O
11-61
Time Parameter of Preven-
ting Oscillation
0~100 0 O O X X X X O
11-62 Selection of Preventing
Oscillation
0: Mode1 1 O O X X X X O
1: Mode2
2: Mode3
11-63 Strong Magnetic Selection 0: Disable 1 X X O O X X X
1: Enable
11-64
Acceleration Speed Gain
Adjustment
0.1~10.0 1.0 - O X X X X X O
11-65 Target Main Circuit Voltage 400V~800V 740 - O X X X X X O
11-66
2 Phase/ 3 Phase PWM
Switch Frequency
6.00~60.00 20 Hz X X O O X X O Note 1
11-67
Soft PWM 2 Frequency
Range
0~12000 0 Hz X X O O O O X Note 1
11-68
Soft PWM 2 Switch
Frequency
6.00~60.00 20 Hz X X O O O O X Note 1
11-69
Gain of Preventing Oscil-
lation 3
0.00~200.00 5.00 % O O X X X X X
11-70
Upper Limit of Preventing
Oscillation 3
0.01~100.00 5.00 % O O X X X X X
11-71
Time Parameter of Prevent-
ing Oscillation 3
0~30000 100 ms O O X X X X X
11-72
Gain of Preventing Oscilla-
tion for switch frequency 1
0.01~300.00 30.00 Hz O O X X X X X
11-73
Gain of Preventing Oscilla-
tion for switch frequency 2
0.01~300.00 50.00 Hz O O X X X X X
*: Refer to the attachment 1.
** If the maximum output frequency of motor is over 300HZ,the frequency resolution is changed to 0.1Hz
Note 1: New added parameter in software V1.20
Note: The parameter of 11-01 can be changed during run operation, the range is 1~16KHz.
Group 12: Monitoring Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
12-00
Extended Display Mode
(LED)
00000 ~77777.
Each digit can be set to 0 to 7 as listed:
00000 - O O O O O O O
*1
*6
0: Default display (frequency&parameters)
VDI100 • Start-up and Installation Manual 49
