gefran VDI100 Start-Up And Installation Manual

Group 12: Monitoring Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
12-60
Inverter Status of Previous
Fault
Display inverter status of previous fault
Description is similar to 12-43
- - O O O O O O O
12-61 Trip Time 1 of Last Fault Display the operation time of last time’s
fault, 12-62 is the days, while 12-61 is the
remaining hours .
- Hr O O O O O O O
12-62 Trip Time 2 of Last Fault - day O O O O O O O
12-63 Recent Warning Messages Display the recent warning messages - - O O O O O O O
12-64 Previous Warning Message Display the previous warning message - - O O O O O O O
12-65 Motor Start Angle 0~360 - - X X X X O X X
12-66 Encoder Angle 0~360 - - X O X O O X X
12-67 Cumulative Energy (kWHr) 0.0 ~ 999.9 kWHr O O O O O O O
12-68 Cumulative Energy (MWHr) 0 ~ 60000 MWHr O O O O O O O
12-69
~
12-75
Reserved
12-76 No-Load Voltage Output 0.0~600.0 - V X X O X X X X
12-77 Reserved
12-78 Z-Phase Bias Value -9999~9999 - Pulse X X X O O X X
12-79 Pulse Input Percentage 0.0~100.0 - % O O O O O O O
12-80 AI1 Frequency Command 0.0~599.0 0 Hz O O O O O O O Note 1
*: Refer to the following attachment 1.
Note 1: New added parameter in software V1.20.
Group 13: Maintenance Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
13-00 Inverter model Selection ---- - - O O O O O O O *4
13-01 Software Version 0.00-9.99 - - O O O O O O O *4
13-02
Clear Cumulative Operation
Hours
0: Disable to Clear Cumulative Operation
Hours
0 - O O O O O O O *1
1: Clear Cumulative Operation Hours
13-03
Cumulative Operation
Hours 1
0~23 - hr O O O O O O O *4
13-04
Cumulative Operation
Hours 2
0~65535 - day O O O O O O O *4
13-05
Selection of Cumulative
Operation Time
0: Cumulative time in power on 0 - O O O O O O O *1
1: Cumulative time in operation
13-06 Parameters Locked
0: Parameters are read-only except 13-06
and main frequency
2 - O O O O O O O *1
1 : User defined parameters
2: All Parameters are Writable
13-07 Parameter Lock key Code 00000~65534 00000 - O O O O O O O Note 1
13-08 Restore Factory Setting 0 : No initialization - - O O O O O O O
2 : 2 wire initialization (440V-60Hz)
3 : 3 wire initialization (440V-60Hz)
4 : 2 wire initialization (415V-50Hz)
5 : 3 wire initialization (415V-50Hz)
6 : 2 wire initialization (380V-50Hz)
7 : 3 wire initialization (380V-50Hz)
8 : PLC initialization
9: 2 wire Initialization (460V-60Hz)
10: 3 wire Initialization (460V-60Hz)
11: 2 wire Initialization (400V-60Hz)
12: 3 wire Initialization (400V-60Hz)
13: 2 wire Initialization (400V-50Hz)
14: 3 wire Initialization (400V-50Hz)
Others: Reserved
VDI100 • Start-up and Installation Manual 53
