gefran VDI100 Start-Up And Installation Manual

Group 13: Maintenance Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
13-09
Fault History Clearance
Function
0: No Clearing Fault History 0 - O O O O O O O *1
1: Clear Fault History
13-10
Parameter Password
Function 2
0 ~ 9999 0 O O O O O O O
13-11 C/B CPLD Ver. 0.00~9.99 - O O O O O O O
13-12 PG Card Id 0~255 0 O O O O O O O *5
13-13 PG Card Ver. 0.00~9.99 - O O O O O O O *5
13-14 Fault Storage Selections
0: Fault Messages of Auto Restart are not
saved.
0 O O O O O O O
1: Fault Messages of Auto Restart are
saved.
13-15 Reserved
13-21 Last time Fault History Exhibit Last time Fault History - - O O O O O O O
13-22 Previous 2 Fault History Exhibit Previous 2 Fault History - - O O O O O O O
13-23 Previous 3 Fault History Exhibit Previous 3 Fault History - - O O O O O O O
13-24 Previous 4 Fault History Exhibit Previous 4 Fault History - - O O O O O O O
13-25 Previous 5 Fault History Exhibit Previous 5 Fault History - - O O O O O O O
13-26 Previous 6 Fault History Exhibit Previous 6 Fault History - - O O O O O O O
13-27 Previous 7 Fault History Exhibit Previous 7 Fault History - - O O O O O O O
13-28 Previous 8 Fault History Exhibit Previous 8 Fault History - - O O O O O O O
13-29 Previous 9 Fault History Exhibit Previous 9 Fault History - - O O O O O O O
13-30 Previous 10 Fault History Exhibit Previous 10 Fault History - - O O O O O O O
13-31 Previous 11 Fault History Exhibit Previous 11 Fault History - - O O O O O O O
13-32 Previous 12 Fault History Exhibit Previous 12 Fault History - - O O O O O O O
13-33 Previous 13 Fault History Exhibit Previous 13 Fault History - - O O O O O O O
13-34 Previous 14 Fault History Exhibit Previous 14 Fault History - - O O O O O O O
13-35 Previous 15 Fault History Exhibit Previous 15 Fault History - - O O O O O O O
13-36 Previous 16 Fault History Exhibit Previous 16 Fault History - - O O O O O O O
13-37 Previous 17 Fault History Exhibit Previous 17 Fault History - - O O O O O O O
13-38 Previous 18 Fault History Exhibit Previous 18 Fault History - - O O O O O O O
13-39 Previous 19 Fault History Exhibit Previous 19 Fault History - - O O O O O O O
13-40 Previous 20 Fault History Exhibit Previous 20 Fault History - - O O O O O O O
13-41 Previous 21 Fault History Exhibit Previous 21 Fault History - - O O O O O O O
13-42 Previous 22 Fault History Exhibit Previous 22 Fault History - - O O O O O O O
13-43 Previous 23 Fault History Exhibit Previous 23 Fault History - - O O O O O O O
13-44 Previous 24 Fault History Exhibit Previous 24Fault History - - O O O O O O O
13-45 Previous 25 Fault History Exhibit Previous 25 Fault History - - O O O O O O O
13-46 Previous 26 Fault History Exhibit Previous 26 Fault History -
- O O O O O O O
13-47 Previous 27 Fault History Exhibit Previous 27 Fault History - - O O O O O O O
13-48 Previous 28 Fault History Exhibit Previous 28 Fault History - - O O O O O O O
13-49 Previous 29 Fault History Exhibit Previous 29 Fault History - - O O O O O O O
13-50 Previous 30 Fault History Exhibit Previous 30 Fault History - - O O O O O O O
Note: Main frequency setting is 12-16 in LCD. It’s equal to Frequency Setting of Speed-Stage 0 (05-01)
Note 1: New added parameter in software V1.20
Group 14: PLC Setting Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
14-00 T1 Set Value 1 0~9999 0 - O O O O O O O
14-01 T1 Set Value 2 (Mode 7) 0~9999 0 - O O O O O O O
14-02 T2 Set Value 1 0~9999 0 - O O O O O O O
14-03 T2 Set Value 2 (Mode 7) 0~9999 0 - O O O O O O O
14-04 T3 Set Value 1 0~9999 0 - O O O O O O O
54 VDI100 • Start-up and Installation Manual
