101 50940193/DP0415
Self-Leveling (Option)
Self-leveling automatically keeps the tilt angle
of the attachment constant, relative to the
ground plane, when the lift arm is raised (A,
Figure 68). This feature is especially useful
when using pallet forks.
Important: Self-leveling operates only when
the lift arm is raised: when the lift arm is
lowered (B), self-leveling is not activated.
Note: Self-leveling is activated by default. To
deactivate self-leveling, see “Self-Leveling
Cancel” on page 102.
Figure 68 – Self-Leveling
Operation
Self-Leveling
Operates When Lift
Arm is Raised
A
Self-Leveling Does
Not Operate When
Lift Arm is Lowered
A
A
B
B
B
