Lifting the Machine Using a Crane or Hoist
Note: Single-point and four-point lift kits are available for lifting the machine. Contact
you dealer for more information.
Contact your dealer for available lift kits for the
machine. Do not lift the machine without an
approved lift kit installed.
Before lifting, check the lift kit for proper installation. Securely fasten
the lifting gear to the machine at the designated lift points.
When using any lift kit, follow the directions included with the lift kit.
Never allow riders in the operator’s compartment while the loader is
lifted.
Keep clear of suspended loads. Keep everyone a safe distance away
from the loader while it is lifted.
The machine may only be crane-lifted with an empty bucket, empty
pallet forks, or with no attachment. Never lift the machine with any other
attachment installed. Never lift the machine with a load in the bucket or
on the pallet forks.
Lift equipment used and its installation is the responsibility of the party conducting the
lift. All rigging MUST comply with applicable regulations and guidelines.
1. If a bucket is attached, make sure it is emptied. If pallet forks are attached, remove any
load from the pallet forks.
2. Raise the arm rests/safety bars to apply the parking brake and lock out the hydraulic
functions.
3. Turn off the engine and remove the ignition key. Close the doors and the engine cover.
Do not allow anyone to stay in the cab.
4. Using suitable lift equipment, hook into the lift kit lifting points. Adjust the length of
the slings or chains so the machine is level when lifted.
Note: The machine may be slightly off level (10 degrees max.) when lifted.
5. Center the hoist over the ROPS/FOPS. To prevent shock loading of the equipment and
excessive swinging, slowly lift the loader off the ground. Perform all movements
slowly and gradually. As needed, use a tag line to help position the loader and keep it
from swinging.
