139 50940193/DP0415
Do not use the starter motor to crank the engine to
prime the fuel system. Damage to the engine
starter motor, coils, pinion/ring gear could result.
8. Start the engine and check for leaks.
Engine Air Cleaner
Important: Failure to follow proper air filter
servicing instructions could result in
catastrophic engine damage.
Do not operate the engine without the air
cleaner components installed or damage to
the engine could occur.
Check the air cleaner intake hose and clamps,
and the mounting bracket hardware daily to be
sure they are properly tightened.
Check, and if necessary replace, the engine air
filter after every 250 hours of use, or every 6
months, or if the filter is damaged, oil- or soot-
laden.
Be sure the air cleaner intake hose, clamps and
mounting bracket hardware are properly
tightened.
Changing Air Filter Elements
1. Perform the “Mandatory Safety Shutdown
Procedure” on page 14.
2. Wait until the engine has cooled.
3. Unlatch clamps (J, Figure 101) on the air
cleaner housing and remove the air filter
cover (L).
4. Clean debris from inside the air cleaner
housing and air filter cover.
5. Carefully remove the outer filter element
(G).
6. Clean dirt from inside the air filter housing
(M).
Important: To prevent debris from entering the engine intake manifold, do not remove
inner filter element (H) while cleaning the inside of the housing.
7. Remove inner filter element (H) only if it needs replacement.
Figure 101 – Engine Air
Cleaner
J
L
G
H
M
