GEIGER Engineering HPD Series - Eoc;Dod; Eoc;Dod

79
EOC/DOD / EOC/DOD
EOC – End of Charge – Einstellung der Ladeschlussspannung (parametrierbar) /
EOC – End of Charge – Setting of charging end voltage (parameterizable)
DOD – Depth of Discharge – Einstellung der Entladeschlussspannung, bzw. Ende der Entladung
(parametrierbar und vom Piloten wählbar) /
DOD – Depth of Discharge – Setting the discharge end voltage or end of discharge (parameterizable and
selectable by the pilot)
Beeinflussung der Zyklenlebenszeit durch End of Charge and Depth of Discharge: /
Influence on cycle life by end of charge and depth of discharge:
State of Charge <------------- -------------> Depth of Discharge
100% 90% 80% 70% 60% 50% 40% 30% 20% 10% 0%
SOC=100%;DOD=100% - 500 Cycles @70%
SOC=100%;DOD=90% - 750 Cycles @70%
SOC=100%;DOD=80% - 1000 Cycles @70%
SOC=90%;DOD=100% - 750 Cycles @70%
SOC=90%;DOD=90% - 1500 Cycles @70%
SOC=90%;DOD=80% - 2000 Cycles @70%
SOC=80%;DOD=100% - 2500 Cycles @70%
SOC=80%;DOD=90% - 3000 Cycles @70%
SOC=80%;DOD=80% - 3500 Cycles @70%
SOC=70%;DOD=100% - 5000 Cycles @70%
SOC=70%;DOD=90% - 5500 Cycles @70%
SOC=70%;DOD=80% - 6000 Cycles @70%
Beeinflussung der Zyklenlebenszeit durch End of Charge bei Lagerung: /
Influence on cycle life by end of charge during storage:
State of Charge <------------- -------------> Depth of Discharge
100% 90% 80% 70% 60% 50% 40% 30% 20% 10% 0%
SOC=90%; 10 Years @70%
SOC=80%; 15 Years @70%
SOC=100%; 5 Years @70%
