Gema OptiGun GA04-E - Technical Data; Electrical Data; Dimensions; Processible Powders

Rev. 00 12/23
OptiGun GA04-E Product description
•
11
Technical Data
Electrical data
OptiGun GA04-E
Nominal input voltage
12 V
Frequency
18 kHz (average)
Nominal output voltage
110 kV
Polarity
negative
(option: positive)
Max. output current
110 µA
Ignition protection
Type A-P acc. EN 50177
Ex 2 mJ 85 °C
Temperature range
0 °C – +40 °C
(+32 °F – +104 °F)
Max. surface temperature
85 °C (+185 °F)
Protection type
IP64
Approvals
0102 II 2D
PTB 23 ATEX 5002
ATTENTION
The OptiGun GA04-E Automatic powder gun may only be
connected to the following control units:
► OptiStar All-in-One CG22-C
OptiStar CG20
MultiStar CG10*
OptiStar CG08
* The PowerBoost functionality is not available.
Dimensions
OptiGun GA04-E
Weight
1000 g
Processible powders
OptiGun GA04-E
Enamel powder
yes
Plastic powder
no
Metallic powder
no
