Owner’s Manual for Power Zone Pro Main Controller 7
General Information
Codes and Standards
• UL 6200 Investigation of Controls for Stationary
Engine Driven Assemblies
• UL 2200 Standard for Stationary Engine Generator
Assemblies
• CSA STD C22.2 No. 14
• IEC/EN 61010-1
• IEC/EN 61000-6-2 EMC Immunity for Industrial
Environments
• IEC/EN 61000-6-4 EMC Emissions Standard for
Industrial Environments
• NFPA 110 (configurable for Level 1 or 2 with
additional optional remote annunciator)
• NFPA 70
Protections
• High/Low Oil Temperature
• High/Low Oil Pressure
• Low Coolant Level
• High/Low Coolant Temperature
• Sender/Sensor Failure
• Over/Under Speed
• Over/Under Voltage
• Over/Under Frequency
• Over Current
• Over Total kW
• High/Low Battery Voltage
• Battery Charge Current
• Phase to Phase and Phase to Neutral Short
Circuits. (I
2
T Algorithm and GFI)
Control Panel and Touch Screen
• Auto/Manual/Off Key Switch
• Alarm Acknowledge Soft Key
• Audible Alarm
• Emergency Stop
