8 Owner’s Manual for Power Zone Pro Main Controller
General Information
Specifications
Environmental Specifications
Operating Temperature -40 °F (-40 °C) to 149 °F (65 °C)
Humidity 2% to 95% Non-Condensing
Enclosure UL Type 1
Weight
3.3 lbs
Power Supply Requirements
Power Supply Source Engine Battery or Battery Charger
Power Supply Voltage 12/24 V
(6 V to 35 V )
Power Supply Wattage 31 Watts
Power Supply Cable 2 wires - 16 AWG recommended
Cranking Dropout 3.5 V
Reverse Polarity Protection Yes
Communication (RS-485)
Number of Ports 2 (1 for customer use, 1 is for internal use only)
Internally Terminated Yes, 120 Ohms
Communication Link 2 wires - RS-485
Communication Cable 2 wires - shielded twisted pair (i.e. Belden 3105A)
Maximum Cable Length 4,000 ft (1,219 m)
Baud Rate RS-485-0 115.2 Kbps; RS-485-1 4.8 to 115.2 kbps (selectable parity and stop bits)
Maximum Number of Devices
32
Communication (CAN)
Number of Ports 2
Internally Terminated Yes, 120 Ohms
Communication Link 2 wires
Communication Cable 2 wires - shielded twisted pair (i.e. Belden 3105A)
Maximum Cable Length 131 ft (40 m)
Baud Rate 250 kbps and 1 Mbps
Maximum Number of Devices
30
Analog/Digital/Inputs/Outputs (all voltages are DC)
Ratings
See
Installation and Operation.
Digital Input 0 V to 5 V, 1.5 mA max, 100 Hz, inputs are internally pulled up to 5V
Digital Input PWM Capable 0 V to 5 V, 5 mA max, 1 Mhz, inputs are internally pulled up to 5V
Digital Output or PWM capable
or Watchdog/Overspeed
0 V to Vopen-drain, Vbattery max, 1 A max sink
Digital Output High Current
Capable
0 V to Vopen-drain, Vbattery max, 2 A max sink
General Purpose Analog Input
0 V to 5 V (10 uA max), 0 V to 10 V (10 uA max); 4-20 mA (50 mA max), or Resistive, 1
kHz
Special Analog Input
0 V to 5 V (10 uA max), 0 V to 10 V (10 uA max); Resistive, 500 Hz
Analog Output 0 V to 5 V, 0 V to 10 V, 10 mA max
Others See Installation and Operation.
