10 Owner’s Manual for Power Zone Pro Main Controller
General Information
NOTE: The communications cables should not be run in the same conduit or in the same wire grouping as any high
voltage or high current conductors.
NOTE: The communications baud rates should be selected to be compatible with other components connected to the
communications bus.
AC Voltage Sensing Inputs (6)
Number of channels 6 + 2 neutral references
Maximum working voltage
600 Vrms ph-ph
Frequency 50 or 60 Hz
AC Current Sensing Inputs (3)
Number of channels 3
Nominal current rating 0-1 A rms
Maximum current rating 3.5 A rms
Frequency 50 or 60 Hz
Input impedance 0.1 Ohms
RPM Sensor Inputs (1)
Number of channels 1
Input type Variable reluctance magnetic pickup
Maximum sensor voltage ± 250 V
Minimum sensor voltage ± 135 mV
Maximum input current 10 mA
