09
9-27
Information
This vehicle has a “hidden” wiper design
which means that the wipers cannot be
lifted manually when they are in their
bottom resting position.
OAD075074ROAD075074R
3. Lift up the wiper blade clip (1). Then
lift up the wiper blade (2).
OAD075075ROAD075075R
4. Whilst pushing the lock (3), pull down
the wiper blade (4).
OAD075076ROAD075076R
5. Remove the wiper blade from the
wiper arm (5).
6. Install a new wiper blade assembly in
the reverse order of removal.
7. Gently put the wipers back down onto
the windscreen.
8. With the Engine Start/Stop button in
the ON position, turn the wiper switch
to any ON position to return the
wipers to the bottom resting position.
To Next Page
