Engine room fuse panel (Engine room sub junction block)
Type Fuse Name
Symbol
Fuse
Rating
Circuit Protected
MICRO
SIDE STEP
SIDE
STEP
20A Not Used
S/HEATER
RR PASS
RR PASS
20A
2ND Seat RH Module, 2ND Air Ventilation
Seat RH Control Module, 2ND Seat RH
Warmer Control Module
PRESAFETY
SEAT BELT 2
2
PRESAFETY
SEAT BELT
30A Pre-Active Seat Belt Unit
PRESAFETY
SEAT BELT 1
1
PRESAFETY
SEAT BELT
30A Pre-Active Seat Belt Unit
P/SEAT RR
PASS 1
1 PASS
25A 2ND Seat RH Module
BURGLAR
ALARM
HORN
15A Burglar Alarm Horn Relay (RLY.4)
RR HTD IND
RR HTD
IND
10A Front A/C Controller
A/C 2
A/C
2
10A Front A/C Control Module
POWER
OUTLET 3
POWER
OUTLET
3
20A Luggage Power Outlet
POWER
OUTLET 4
POWER
OUTLET
4
20A Rear Console Power Outlet
LDC
LDC
10A
Front Radar LH/RH, Rear Radar LH/RH,
Head-Up Display, Smart Phone Wireless
Charger, Instrument Cluster, Front A/C
Controller, Front Console Keyboard, Rear
A/C Control Panel
To Next Page
