09
9-59
Luggage room (Rear sub junction block)
Fuse Name
Symbol
Fuse
Rating
Circuit Protected
B+2
2
30A
ICU Junction Block (IPS2, IPS5, Fuse - F22, F29,
F30, F37, F38, F47)
DCU3
DCU
3
20A Dosing Control Module
DCU4
DCU
4
10A Front NOX Sensor, Rear NOX Sensor
CHILD LOCK
15A Child Lock/Unlock Relay
DCU1
DCU
1
20A Dosing Control Module
P/SEAT RR
LH 1
RR LH 1
30A 2ND Seat LH Module
DCU2
DCU
2
20A Dosing Control Module
AMP
AMP
25A AMP, Low DC-DC Converter (AMP)
P/SEAT 3RD 1
3RD 1
25A 3RD Seat LH/RH Reclining Folding Actuator
CURTAIN
CURTAIN
20A Rear Door Curtain Module
WIPER RR
15A Rear Wiper Relay, Rear Wiper Motor
P/DOOR LH
P/DOOR
LH
15A Driver/Passenger Door Latch, Rear Door Latch LH
P/SEAT 3RD 2
3RD 2
30A 3RD Seat Module
CURTAIN
CURTAIN
20A ELSD Control Module
S/HEATER RR
LH
RR LH
20A
2ND Seat LH Module, 2ND Air Ventilation Seat LH
Control Module, 2ND Seat LH Warmer Control
Module
POWER T/
GATE
30A Power Tail Gate Unit
P/SEAT RR
LH 2
RR LH 2
20A
2ND Seat LH Reclining Folding Actuator, 2ND Seat
LH Module
To Next Page
