09
9-61
Luggage room (Battery junction block)
Fuse Name
Symbol
Fuse
Rating
Circuit Protected
B+5
5
125A
[LHD] E/R SUB Junction Block (B+)
[RHD] E/R Junction Block (B+)
B+6
6
100A
Rear Junction Block (DCU Relay, Fuse - S1, F3, F6,
F9, F12, F14, F16, F19, F20, F22, F24, F25, F26)
B+1
1
50A
ICU Junction Block (Long Term Load Latch Relay,
Short Term Load Latch Relay, IPS1, IPS3, IPS4, IPS6,
IPS7)
TRAILER
50A Trailer Connector
B+4
4
50A ICU Junction Block (Fuse - F2, F3, F27, F31, F45)
B+3
3
50A
ICU Junction Block (Fuse - F25, F26, F33, F34, F35,
F36, F41, F42, F43, F44)
AMS
AMS
10A Battery Sensor
To Next Page
