Safety system
3-40
Second row centre seatbelt
(3-point rear centre seat belt)
OJX1039015LOJX1039015L
When using the rear centre seat belt, the
buckle with the “CENTER” mark must be
used.
Information
If you are not able to pull out the safety
belt from the retractor, firmly pull the belt
out and release it. After release, you will be
able to pull the belt out smoothly.
WARNING
Make sure that the seatback is locked in
place when using the rear centre seat
belt.
If not, the seatback may move when
there is a sudden stop or collision,
which could result in serious injury.
Pre-tensioner seat belt
OJX1030118ROJX1030118R
[1] : Retractor pre-tensioner seat belt
Front seat and second row outboard seat (if
equipped)
Your vehicle is equipped with driver’s and
front passenger’s and rear passengers
Pre-tensioner Seat Belts (Retractor
Pre-tensioner). The purpose of the pre-
tensioner is to make sure the seat belts
fit tightly against the occupant’s body
in certain frontal or side collision(s).
The pre-tensioner seat belts may be
activated in crashes where the frontal
or side collision(s) is severe enough,
together with the air bags.
When the vehicle stops suddenly, or if
the occupant tries to lean forward too
quickly, the seat belt retractor will lock
into position.
In certain frontal collisions, the pre-
tensioner will activate and pull the seat
belt into tighter contact against the
occupant’s body.
If the system senses excessive tension
on the driver or passenger’s seat belt
when the pre-tensioner system activates,
the load limiter inside the retractor
pre-tensioner will release some of the
pressure on the affected seat belt (if
equipped with load limiter).
