SCISSOR COMPONENTS
43 Use a soft metal drift to remove the number 2
center pivot pin (index #5) at the ground
controls side.
44 Remove the retaining fasteners from the
number 2 pivot pin (index #15) at the non-steer
end of the machine.
45 Use a soft metal drift to tap the number 2 pivot
pin (index #15) halfway out at the non-steer end
of the machine. Remove the number 2 outer
arm (index #14) from the ground controls side
of the machine.
Bodily injury hazard. The number
2 outer arm at the ground controls
side may become unbalanced and
fall if not properly supported when
removed from the machine.
46 Attach a lifting strap from an overhead crane to
the number 2 outer arm (index #14) at the
battery pack side.
47 Remove the external snap rings and retaining
fasteners from the number 2 center pivot pin
(index #5) at the battery pack side.
48 Use a soft metal drift to remove the number 2
center pivot pin (index #5) at the battery pack
side.
Bodily injury hazard. The number
2 outer arm at the battery pack
side may become unbalanced and
fall if not properly supported when
removed from the machine.
49 Use a soft metal drift to tap the number 2 pivot
pin (index #15) in the other direction at the non-
steer end. Remove the number 2 outer arm
(index #14) from the battery pack side of the
machine.
Bodily injury hazard. The number
2 outer arm at the battery pack
side may become unbalanced and
fall if not properly supported when
removed from the machine.
50 Attach a lifting strap from an overhead crane to
the number 2 inner arm (index #13).
51 Remove the retaining fasteners from the
number 2 pivot pin (index #6) at the steer end
of the machine.
52 Use a soft metal drift to remove the number 2
pivot pin (index #6). Remove the number 2
inner arm (index #13) from the machine.
Bodily injury hazard. The number
2 inner arm may become
unbalanced and fall if not properly
supported when removed from the
machine.
53 Remove the safety arm from the number 2 inner
arm (index #13) that was just removed.
54 Attach a lifting strap from an overhead crane to
the number 1 inner arm (index #8).
