Section 3 • Scheduled Maintenance ProceduresJanuary 2012
Part No. 228901 GS-30 • GS-32 • GS-46 • GS-47 3 - 5
Maintenance Inspection Report
Checklist B Y N R
B-1 Batteries
B-2 Electrical wiring
B-3 Electrical contactor
B-4 Tires and wheels
B-5 Emergency stop
B-6 Key switch
B-7 Horn (if equipped)
B-8 Drive brakes
B-9 Drive speed - stowed
B-10 Drive speed - raised
B-11 Drive speed - slow
B-12 Hydraulic oil analysis
B-13 Tank venting system
B-14 Latch components
B-15 Voltage inverter
(if equipped)
B-16 Down limit switch and
pothole limit switches
B-17 Up limit switch and
max. drive height limit
switches (if equipped)
Checklist C Y N R
C-1 Pressure transducer
and platform height
sensor (if equipped)
C-2 Platform overload
(if equipped)
C-3 Breather cap - models
with optional oil
Checklist D Y N R
D-1 Scissor arm wear pads
D-2 Hydraulic filter
Checklist E Y N R
E-1 Hydraulic oil
Comments
Checklist A Y N R
A-1 Inspect the manuals
and decals
A-2 Pre-operation
inspection
A-3 Function tests
Perform after 40 hours:
A-4 30 day service
Perform every 100 hours:
A-5 Grease steer yokes
Instructions
· Make copies of this report to use for
each inspection.
· Select the appropriate checklist(s) for
the type of inspection to be
performed.
Daily or 8 hours
Inspection: A
Quarterly or 250 hours
Inspection: A+B
Semi-annually or
500 hours
Inspection: A+B+C
Annually or
1000 hours
Inspection: A+B+C+D
Two year or
2000 hours
Inspection: A+B+C+D+E
· Place a check in the appropriate box
after each inspection procedure is
completed.
· Use the step-by-step procedures in
this section to learn how to perform
these inspections.
· If any inspection receives an “N”, tag
and remove the machine from service,
repair and re-inspect it. After repair,
place a check in the “R” box.
Legend
Y = yes, acceptable
N = no, remove from service
R = repaired
Model
Serial number
Date
Hour meter
Machine owner
Inspected by (print)
Inspector signature
Inspector title
Inspector company
To Next Page
