January 2012Section 4 • Repair Procedures
4 - 118 GS-30 • GS-32 • GS-46 • GS-47 Part No. 228901
SCISSOR COMPONENTS
13 Use the Menu Up or Menu Down buttons to
select No Load calibration.
14 Press the Enter button to select No Load
calibration.
15 Press the Enter button to confirm no load is in
the platform.
16 At the ground controls, press and hold the
Function Enable and Platform Up buttons until
the platform reaches maximum height.
17 When the platform reaches maximum height,
press the ground controls Enter button. Allow
the ground controls to gather data.
18 When prompted, press and hold the
Function Enable and Platform Down buttons
to lower the platform. The platform will move
down, then automatically stop at a
predetermined point to gather data. Allow the
ground controls to gather data.
19 Continue pressing the Function Enable and
Platform Down buttons throughout the lowering
and data gathering sequence. The machine will
stop to gather data and lower several times
before the machine reaches the stowed
position. When the platform reaches the stowed
position, press the Enter button.
20 When prompted, push the red Emergency Stop
button in to complete the No Load Calibration
procedure.
To Next Page
