Section 2 • SpecificationsJanuary 2012
Part No. 228901 GS-30 • GS-32 • GS-46 • GS-47 2 - 7
Valve Coil Resistance
Note: The following coil resistance specifications are at
an ambient temperature of 68°F / 20°C. As valve coil
resistance is sensitive to changes in air temperature,
the coil resistance will typically increase or decrease by
4% for each 18°F / -7.7°C that your air temperature
increases or decreases from 68°F / 20°C.
Description Specification
Solenoid valve, 3 position 4 way 27.2Ω
20V DC with diode (schematic items F and AC)
Solenoid valve, 3 position 4 way 19Ω
20V DC with diode (schematic item E)
Solenoid valve, 2 position 4 way 19Ω
20V DC with diode (schematic item H and AI)
Solenoid valve, 2 position 2 way N.C. 25Ω
20V DC with diode (schematic item N)
Solenoid valve, 2 position 4 way 19Ω
20V DC with diode (schematic items AE)
Solenoid valve, 3 position 5 way 19Ω
20V DC with diode (schematic item AG)
Solenoid valve, 2 position 2 way 27.2Ω
20V DC with diode (schematic item CA, CB, CC
and CD)
Solenoid valve, 3 position 4 way 19Ω
20V DC with diode (schematic item BA)
Solenoid valve, 2 position 2 way 23.9Ω
20V DC with diode (schematic item DO)
Continuous improvement of our products is a
Genie policy. Product specifications are
subject to change without notice.
