Operator Manual
Operation 4.16 © Genmega 2012
Step 4
Feed the paper over the bar behind the roll and
under the spring loaded tension bar. Slide the paper
through the guides. The paper will not feed until the
machine is initialized (powered on). If the paper
does not feed, make sure the paper is all the way in
the loading guide. Also make sure the roller
assembly is closed (see below)
Step 5
The roller assembly can be opened by pressing
down on the green lever in front of the printer.
Step 6
To close the roller assembly, lift up on the rollers.
The roller assembly must be completely closed
before the printer will operate. Press up on the
roller assembly rather than on the green lever to
close.
When finished loading paper, close the top bezel
and remove the key.
