GeoVision GV-IP Decoder Box Series User Manual

14
GV-IP Decoder Box Plus
1
4
2
3
5
Figure 1-6
GV-IP Decoder Box Lite
Figure 1-7
No. Name Function
1
SD Card
Slot
Connect to a SD card for local storage of snapshots and firmware
upgrade. Only supported by GV-IP Decoder Box Plus.
2 Default
Reset the device to the default factory settings. Use a pin to press the
default button for about 10 seconds. The system will then reset and
reboot itself shortly. See 5.2 Restoring Default Settings.
3 USB
Connect to a GV-Joystick V2, USB mouse, or USB storage device.
Only supported by GV-IP Decoder Box Plus.
4
LED Indicators
The red LED indicates the power is supplied.
The green LED indicates the system is ready for use.
5 Audio In Not functional.
