GeoVision GV-IP Decoder Box Series User Manual

Getting Started
39
2
 ONVIF: Select this protocol if your camera adheres to ONVIF.
 RTSP over HTTP: The RTSP protocol uses an HTTP port for data streaming from
the IP camera.
 RTSP over TCP: The RTSP protocol uses a TCP port for data streaming from the
IP camera.
 RTSP over UDP: The RTSP protocol uses a UDP port for data streaming from the
IP camera.
Note: GV-IP Decoder Box Light does not support RTSP connection.
4. Click OK. The camera is added to the list.
5. Add channels to the Connection Information column. See Step 6, 2.7.1 Adding a GV-IP
Device.
6. Click Save.
The cameras on the Connection Information column will be updated to the GV-IP Decoder
Box Series / GV-Pad Mini and displayed on the monitor with the looping interval of 30
seconds by default.

GeoVision GV-IP Decoder Box Series Specifications

General

Brand	GeoVision
Model	GV-IP Decoder Box Series
Category	Digital Camera
Language	English
