Administrator Mode
91
4 4
C. To draw the 2
nd
detection area, repeat steps 4A and 4B. Each
detection region is numbered.
D. To clear any defined area, click
under the image, and
click the X icon to remove it. Click again to return to
the setting.
5. To configure the intrusion direction, select the detection direction from
0 to 1, 0 to 1, or both in Direction Setting. The alarm sets off when
the intruder moves through the first detection area into the second
area in the defined direction, or vice versa.
Figure 4-16
6. Use the Alarm Time slider to specify the time length required for the
intrusion alarm to be triggered when the system detects any intruders
within the defined areas. The default setting is 5 seconds.
7. To activate intruder detection settings at specific time periods each
day, create a schedule. For details, see Step 6 in 4.2.1 Motion
Detection.
8. Click the Apply button to start intruder detection.
