GV-LPC1200 / LPR1200
Camera
Image Sensor
Megapixel B/W progressive scan CCD
Picture Elements
1280 (H) x 720 (V)
Camera Type
B/W
Shutter Speed
Automatic: 1/1000 ~ 1/10000 sec
Manual: 1/250 ~ 1/2000 sec
S/N Ratio
52 dB
Max. Speed
200 km/h (124.27 mph)
Lens
Megapixel
1 MP
Lens Type
Motorized varifocal lens
Focal Length
4.7 mm ~ 47 mm
Maximum Aperture
F/3.5
Image Format
1.3”
Horizontal FOV
59.9° ~ 6.4°
Focus
Auto
Zoom
10x optical zoom
Operation
Iris
Auto
IR LED Quantity
8 high power IR LEDs
IR Distance
10 ~ 20 m (32.8 ~ 65.6 ft)
Operation
Video Compression
H.264, MJPEG
Video Stream
Dual streams from H.264 and MJPEG
Frame Rate
30 fps at 1280 x 720
*The frame rate and the performance may vary depending
on the number of connections and data bitrates (different
scenes)
Image Setting
Brightness, Contrast, Sharpness, Gamma, Image
Orientation, Shutter Speed, Defog, Maximum Video Gain
Audio Compression
G.711, AAC (Optional)
Audio Support
Two-way audio
