Get Packed GPAS-158 - Identification Data of the Machine

17
STRAP WIDTH
9mm/12mm ONLY (BY ADJUSTMENT)
STRAP THICKNESS
0.45mm – 0.7mm
STRAP COIL
Coil diameter: 200mm (230mm/280mm as option)
Width: 190mm-200mm
MACHINE SIZE
1130mm (L)* 619mm (W) * 1535mm (H)
NET WEIGHT
180 Kg
TENSION RANGE
50 N – 650 N
SPEED
37 STRAP/MIN
TABLE HEIGHT
835mm
NOISE EMISSION
78 dB
AMBIENT TEMP.
5℃ - 40℃
MIN PACKAGE SIZE
70mm*20mm
MAX PACKAGE SIZE
850mm*600mm (standard arch size)
2.6 Identification Data of the Machine
Each model is provided with a plate where it is easy to recover data which must be
communicated to the manufacturer in case of problem or when requesting spare parts etc.
(ref. 1-2-3-4) This plate also carries electrical technical data for installation of the machine.
(ref. a-b-c-d-e-f-g).
1. Model
2. Serial Number
3. Year of Manufacture
4. Doc. Number
a. Rated voltage (V)
b. Rated Current (A)
c. Frequency (Hz)
d. Short Circuit Rating (A)
e. Phase (PH)
f. Rated power (Watts)
g. Weight (kg)
1
2
3
4
a b c d e f g
