4.4 Service Mode Page
For service only, this function allows technician go detail check (password protect, please
contact for password), you could rotate the Potentiometer to select manual function then
press Start Button to run.
➢ FEED
Press Start button to manual run M2 motor forward
➢ REFEED
Press Start Button to manual run M2 motor backward
➢ CAM
Press Start Button to manual run M1 motor forward
➢ 2
nd
FEED SOLENOID
Press Start Button to activate 2
nd
feed solenoid
➢ AUTO FEED MOTOR
Press Start Button to run auto threading motor
➢ Language (Option)
Rotate the nut for switch language & Press Start Button to confirm
