5.2 Pool Feed pressure & gap
The machine is well set for the Pool Feed pressure and gap. It might need some adjustment
when you have smooth strap on this machine.
Note: Excessive pressure for Pool Feed Roller might cause strap squeezed then jammed
Note: Insufficient pressure for Pool Feed Roller might cause insufficient strap amount in
Pool Box.
The adjustment of Pool Feed pressure and gap as following:
a. Open the front door and side door
b. Two screws from the side door could adjust the limit plate to control gap between Pool
Feed Rollers, the suggested setting is 0.1mm for the gap. Then from the front door,
there’s one spring with nut to adjust pressure between Pool Feed Rollers.
