FIGURE 6-1 AUTO THREADING UNIT
NO
PART NUMBER
Description
QTY
A
P02-0363100
AUTO FEED GUIDE ASSEM
1
1
P0501-0018500
AUTO THREAD MOTOR
1
2
P01-0552900
AUTO THREAD MOTOR BRACKET
1
3
P1101-0504012AN
SCREW M4*12
1
4
P1102-0104AN
NUT, M4
1
5
P1102-0110AZ
NUT, M10
1
6
P02-0372600
ADJUST RING
1
7
P01-0553000
FIXED RING
1
8
P1201-0010900
AUTO THREADING SPRING
1
9
P02-0340900
ADJUSTING FIXER
1
10
P06-0064800
FRICTION PLATE
2
11
P02-034080A
AUTO FEED GUIDE
1
12
P02-0372400
AUTO FEED SHAFT
1
13
P1104-020608ZZ0
BEARING
1
14
P02-0340600
BEARING SEAT
1
15
P1101-0905012AN
SCREW M5*12L
1
16
P02-0372500
SUPPORT RING
1
17
P01-0607200
SPACER 15MM
1
