Get Packed GPAS-158 - Page 58

58
FIGURE 8-1 ARCH UNIT
NO
PART NUMBER
Description
QTY
A
CONTROL BOX UNIT – FIG 9-1
1
B
ARCH (850*600MM)
1
C
ARCH SUPPORT UNIT – FIG 11-1
2
D
EJECT PIN UNIT – FIG 12-1
4
E
UPPER ARCH OPEN UNIT FIG 31-1
1
4.1
P01-054712A
ARCH COVER (RIGHT)
1
4.2
P01-0549620
BRUSH FIX PLATE (RIGHT)
1
4.3
P13-0001100
BRUSH (RIGHT)
1
4.4
P1101-0104010AZ
SCREW M4*10
2
5.1
P01-054732A
ARCH COVER (UPPER)
1
5.2
P13-0000900
BRUSH (UPPER)
2
5.3
P01-0549600
BRUSH FIX PLATE (UPPER)
2
5.4
P1101-0104010AZ
SCREW M4*10
4
6.1
P01-054722A
ARCH COVER (LEFT)
1
6.2
P01-0549620
BRUSH FIX PLATE (LEFT)
1
6.3
P13-0001100
BRUSH (LEFT)
1
6.4
P1101-0104010AZ
SCREW M4*10
2
7
P02-033870A
ARCH GUIDE SHAFT
2
9
P1116-P0080
O RING
2
11
P02-0338900
ARCH GUIDE SEAT
2
12
P1101-0905012AN
SCREW M5*12
6
13
P1101-0704006AB
SCREW M4*6
2
14
P1105-0108B
C-RING S-8
2
15
P01-0554800
ARCH ADJUST PLATE
1
16
P1101-0508025AN
SCREW M8*25
1
17
P1102-0108AZ
HEX NUT, M8
1
18
P06-006500A
CUSHION M8
1
19
P1202-0007300
SPRING
1
20
P1101-0505020AN
SCREW M5*20
1
21
P1103-0205Z
SPRING WASHER φ5
1
22
P1103-010512N
WASHER φ5*12
1
23
P1102-0105AN
HEX NUT, M5
1
24
P1101-0904018AN
SCREW M4*18
4
