Get Packed GPAS-158 - Page 63

63
FIGURE 10-1 INNER ARCH UNIT
NO
PART NUMBER
Description
QTY
1
P01-054751C
INNER ARCH BRACKET
1
2
P06-0064000
9~12MM BANDWAY
2
3
P06-0064300
9~12MM BANDWAY CORNER
4
4
P06-0064200
9~12MM BANDWAY
1
5
P06-0064240
9~12MM BANDWAY
1
6
P06-0064100
9~12MM BANDWAY
2
7
P02-0339100
BANDWAY CONNECTING GUIDE (L)
1
8
P02-033920A
BANDWAY CONNECTING GUIDE (R)
1
9
P01-0554400
ARCH LEFT GUIDE PLATE
1
10
P01-055450A
ARCH RIGHT ADJUSTING PLATE
1
11
P01-055460B
ARCH BRIDGE
1
12
P02-033880A
ARCH GUIDE SEAT
2
13
P1104-01082
LINEAR BEARING
2
14
P01-0556200
ARCH OPENING BRACKET
1
15
P02-0339000
SHAFT
1
16
P1104-020628ZZ0
BEARING 628ZZ
1
17
P01-055470B
HEATER PLATE COVER
1
18
P1105-0115B
C RING S-15
4
19
P1101-0504012AN
SCREW M4*12
2
20
P1101-0605008AN
SCREW M5*8
4
21
P1105-0108B
C RING S-8
2
22
P1101-0904008AN
SCREW M4*8
4
23
P1101-0405012AN
SCREW M5*12
4
24
P1101-0204008AZ
SCREW M4*8
2
26
P1101-14040080
SCREW M4*8
12
A
BEARING FOLLOWER UNIT – FIG 30-1
2
