Get Packed GPAS-158 - Part List for Machine Assemble

67
FIGURE 13-1 MACHINE ASSEMBLE
NO
PART NUMBER
Description
QTY
1
MACHINE FRAME UNIT (W 850)
1
2
CASTER UNIT – FIG 1-1
2
3
DISPENSER UNIT – FIG 15-1
1
4
POOL FEED UNIT – FIG 2-1
1
5
P01-0575500
POOL LEVER STOPPER
1
6
P01-054954A
POOL COVER
1
7
P0319-S15834
PROXIMITY SWITCH QL-05N
1
8
P01-0041700
PROXIMITY SWITCH PLATE
1
9
P1202-0000100
SPRING
1
10
P01-0547920
DOOR
2
11
P01-0547820
UPPER COVER
2
12
P1103-0204Z
SPRING WASHER φ4
4
13
P1101-0504010AN
SCREW M4*10
4
14
P06-0064610
POOL SPACER
4
15
P1103-0205Z
SPRING WASHER φ5
12
16
P1103-010512N
WASHER φ5*12
10
17
P1102-0105AN
NUT M5
5
18
P01-055090A
ELECTRICAL BOX
1
19
FRONT TABLE UNIT – FIG 4-1 (W 850)
1
20
REAR TABLE UNIT – FIG 5-1 (W 850)
1
21
P0311-010002800
MAIN POWER SWITCH
1
22
P01-0553500
TABLE SENSOR BRACKET
1
23
P0319-S15831
TABLE SENSOR
1
24
P01-0548200
ELECTRICAL BOX COVER
1
25
P01-055070A
ELECTRIC PLATE
1
26
P01-0551000
CABLE FIXER PLATE
4
27
P1101-0605006AN
SCREW M5*6
3
28
SIDE DOOR UNIT – FIG 16-1
1
29
P02-0338500
POOL SPRING ADJUST ROD
1
30
P1102-0106AZ
NUT M6
2
31
P1103-0206Z
SPRING WASHER φ6
1
32
P1101-0608012AN
SCREW M8*12
4
33
P1106-020000100
SIDE DOOR MAGNET
2
34
P1101-0505025AN
SCREW M5*25
2
