Get Packed GPAS-158 - Page 71

71
FIGURE 15-1 DISPENSER UNIT
NO
PART NUMBER
Description
QTY
1
P1124-0001600
SLIDE
2
2
P01-055190D
DISPENSER SEAT
1
3
P02-033930A
DISPENSER SHAFT
1
4
P1104-026304ZZ0
BEARING, 6304ZZ
2
5
P02-0339400
BRAKE ARM SPACER
1
6
P01-0041200
PULLEY BRACKET
1
7
P06-000680C
PULLEY
1
8
P1101-0504030AN
SCREW M4*30
2
9
P1103-0204Z
SPRING WASHER φ4
7
10
P1101-0506016AN
SCREW M6*16L
5
11
P1102-0106AN
NUT M6
5
12
P1202-0000400
SPRING
1
13
P01-0551700
SLIDE HANDLE
1
14
P01-055180B
FIXING PLATE
1
15
P1106-010000400
SIDE DOOR MAGNET
1
16
P06-0058200
DISPENSER
2
17
P06-0058100
DISPENSER KNOB
1
18
P06-0058300
DISPENSER CONNECT PULLEY
1
19
P06-0058400
BRAKE WHEEL
1
20
P06-0058500
(OPTION) EXTENSION CLAW
3
21
P1105-0319B
SNAP RING E19
1
22
P1103-0206Z
SPRING WASHER φ6
4
23
P1101-0204012AZ
SCREW M4*12
2
24
P1102-0104AN
NUT M4
2
25
P01-0133100
DISPENSER SPACER
1
26
P1105-0125B
C RING S-25
1
27
P02-0076300
PIN
1
28
P1109-030801Z
PIN R-08
1
29
P01-0552000
BRAKE ARM
1
30
P02-0339500
PULLEY SHAFT
1
31
P01-0552100
BELT FIXER
2
32
P02-0339600
BELT FIX BLOCK
2
