FIGURE 19-1 TENSION UNIT
NO
PART NUMBER
Description
QTY
1
P02-0337100
TENSION SEAT
1
2
P02-0310400
BEARING
1
3
P1101-0504020AN
SCREW M4*20
1
4
P1103-0204Z
SPRING WASHER φ4
1
5
P1102-0104AN
NUT M4
1
6
P1202-0012700
SPRING
1
7
P1103-010409N
WASHER ψ4*9
1
8
P0701-0004800
TENSION GEAR
1
9
P02-0337200
TENSION DRIVEN ROLLER
1
10
P1104-026000ZZ0
BEARING
2
11
P02-033730A
TENSION ARM SHAFT
1
12
P1103-011016B4S
WASHER ψ10*ψ16*0.4
1
13
P1108-010505010G
KEY 5*5*10
1
14
P1108-010404012G
KEY 4*4*12
1
15
P1105-0115B
C RING S-15
2
16
P1105-0110B
C RING S-10
1
17
P1101-0104006AZ
SCREW M4x6
4
18
P02-0338300
TENSION ROLLER SPACER
1
