Get Packed GPAS-158 - Page 82

82
FIGURE 20-1 SEALER UNIT
NO
PART NUMBER
Description
QTY
1
P1101-0504016AN
SCREW M4*16
2
2
P1101-0504016AN
SCREW M4*16
1
3
P1102-0104AZ
NUT M4
2
4
P02-0333700
SEALER SEAT
1
5
P02-033380B
SLIDING TABLE SUPPORT RIGHT
1
6
P02-033390B
SLIDING TABLE SUPPORT LEFT
1
7
P02-033400C
SLIDING TABLE
1
8
CAM UNIT – FIG 21-1
1
9
SEPERATOR UNIT – FIG 23-1
1
10
P01-055650A
SLIDING TABLE SPRING BRACKET
1
11
P06-0065300
CUSHION
2
12
P02-0336400
MOTOR SUPPORT
4
13
FEEDING UNIT – FIG 17-1
1
14
P0501-0018800
CAM REDUCER MOTOR (200-240V/60 135W)
1
P0501-0018700
CAM REDUCER MOTOR (100-120V/60 135W)
1
P0501-0020900
CAM REDUCER MOTOR (100-120V/50 135W)
1
P0501-0021000
CAM REDUCER MOTOR (200-240V/50 135W)
1
15
HEATER PLATE UNIT – FIG 24-1
1
16
SEPERATOR ARM UNIT – FIG 29-1
1
17
P02-0334800
SHAFT - HEATER
1
18
P02-0334400
SHAFT - ARM
1
19
P1103-010612N
WASHER φ6
4
20
P1103-0206Z
SPRING WASHERφ6
4
21
P1101-0506080AN
SCREW M6*80
2
22
P1101-0506060AN
SCREW M6*80
2
23
ARCH OPENER UNIT – FIG 25-1
1
24
P0319-S158422
FAN 220V
1
P0319-S158421
FAN 110V
1
25
P1202-0011400
SEPERATING ARM SPRING
1
26
P1102-01081N
NUT M8
1
27
P1103-0208Z
SPRING WASHER φ8
1
28
P1103-010816N
WASHERφ8*16
1
