FIGURE 21-1 CAM UNIT
NO
PART NUMBER
Description
QTY
1
P02-0335400
BEARING SEAT LEFT
1
2
P02-0336100
BEARING SEAT RIGHT
1
3
P02-0334900
CAM SHAFT
1
4
P1104-026004ZZ1
BEARING
2
5
P02-0336000
CAM (HEATING)
1
6
P02-0335900
CAM (END-GRIPPER)
1
7
P02-0335800
CAM (WELDING CLAMP)
1
8
P02-0335700
CAM (SLIDING TABLE)
1
9
P02-0335600
CAM (HOLDING GRIPPER)
1
10
P02-0335000
CAM (ARCH)
1
11
P1105-0120B
C RING S-20
1
12
P02-0335300
SPACER
1
13
P02-0335500
SPACER SMALL
3
14
P02-0336200
CAM (TENSION)
1
15
P1108-010505025G
KEY 5x5x25L
2
16
P1101-0704006AB
SCREW M4*6
1
17
P02-033630A
CAM (REFEED FORCE)
1
18
P1101-0908020AN
SCREW M8*20
1
19
P1108-010505038G
KEY 5x5x38L
1
20
P1108-010505030G
KEY 5x5x30L
2
21
P01-0559300
WASHER M8
1
22
P01-0612100
CAM (REFEED)
1
23
P01-0612200
CAM (ZERO POSITION)
1
24
P02-0360400
CAM SPACER
1
