FIGURE 22-1 CLAMP SEAT UNIT
NO
PART NUMBER
Description
QTY
1
P02-033330A
CLAMP SEAT
1
2
P02-0361800
END GRIPPER UNIT
1
3
P02-0361900
WELDING CLAMP UNIT
1
4
P02-0362000
HOLDING GRIPPER UNIT
1
5
P02-033340A
CLAMP SEAT COVER
1
6
P1202-0011300
SPRING
1
7
P1202-0009100
SPRING
2
8
P02-0333600
SCREW
3
9
P1101-0506020AN
SCREW M5x10
2
10
P1103-0206Z
SPRING WASHER φ6
2
11
P1103-0205Z
SPRING WASHER φ5
4
12
P1101-0505015AN
SCREW M5x15
4
