Specifications A-3
Parts Specifications
Dimension (L×W×H) 289.68×227.77×59.4 mm (11.4×8.97×2.3 inch)
Weight Less than 2.5 kg (5.5 lb)
Temperature
Operating: 0 °C (32 °F) to 55 °C (131 °F)
–20 °C (4 °F) to 55 °C (131 °F) – low temperature option
Non-operating: –40 °C (–40 °F) to 70 °C (158 °F)
Humidity 5 % to 95 % relative, non-condensing
Altitude Operating: 15,000 ft
Non-operating: 40,000 ft
Shock Operating: 15 g, 11 ms half-sine wave
Non-operating: 50 g, 11 ms half-sine wave
Vibration Sinusoidal wave vibration:
Operating: 10~55 Hz / 0.075, 55~500 Hz / 1 g
Non-operating: 10~55 Hz / 0.15, 55~500 Hz / 2 g
Random vibration:
Operating: MIL-STD-810F, 514.5C-1 – highway truck exposure
Non-operating: MIL-STD-810F, 514.5C-17
Drop 100 cm drop 26 times onto plywood plate surface
Enclosure IEC 529, MIL-STD-810F, IP54 / NEMA4
(with input/output doors closed)
Environment
ESD Air discharge: 0~8 KV (included) no error; 9~15 KV allow soft error
Contact discharge: 0~6 KV (included) no error; 7~8 KV allow soft
error
EMC FCC part 15, subpart B, class B
Safety CE, UL, TUV, TUV/CB
Regulation
Other WHQL, E-mark, WEEE, EPEAT
RoHS 6 European union banned materials, EPEAT silver Green Product
Coverage
Other 12 universal GP product banned materials, ENERGY STAR
