Ref
Component Description
Indicators
Power Lights blue when the device is turned on.
Blinks blue when the device is in Suspend mode.
Suspend mode is a deep sleep mode that saves more
battery power. The device automatically enters
Suspend mode after remaining idle in Sleep mode for
some time. The device will wake up upon an external
event (such as a button press or an alarm).
RF (Radio
Frequency)
Blinks blue when the RF radio of any RF feature
(WLAN/Bluetooth/WWAN) is on.
Battery
Charge
Lights amber when the battery is being charged.
Lights green when battery charging is completed.
Blinks green to indicate the battery’s built-in high
temperature protection mechanism is activated.
Blinks red when the battery’s capacity is below 10%.
Blinks amber when the battery charging is in an
abnormal state. Replace the battery in case this happens.
Microphone
Receives sound and voice.
Touchscreen Displays and receives information for the device.
