Getinge Maquet PowerLED II Maintenance Manual

Adjustments
Adjusting the Valia spring arms
5
Maquet PowerLEDII
01810 EN 03
25 / 56
1
2
3
4
5
6
Fig.24: Fitting the tabs
• Check that the matt inner surface and shiny outer surface of the tabs are correctly positioned
to ensure correct mounting in the grooves.
• Position the spring arm in the high position 1 to insert the first two tabs.
• Insert the tab in the grooves 3 .
• Raise the tab 4 back into its housing.
• Lock the tab by pushing it into its housing using a flat screwdriver, until it clicks 5 .
• Position the spring arm in the low position 2 , then proceed in the same way to install the
second tab.
• Move the arm up and down to check that the tabs slide without coming out of their grooves.
